HanWei Automated Precision Galvanometer Laser Welding Head For Plastic Welding
The galvanometer laser welding head is an optical scanning module specifically engineered for high-precision automated welding applications. By utilizing high-precision galvanometer motors to drive reflective mirrors for two-dimensional deflection, the device projects a focused laser beam onto the workpiece surface in a non-contact manner at exceptional speeds. With compact modular design, replacing traditional mechanical axis movements to significantly enhance welding cycle times and path flexibility.
Technical Advantages
The core advantage of the galvo welding head lies in its exceptional dynamic response and trajectory programmability. The built-in high-speed digital control system supports real-time generation of circular, spiral, figure-8, and custom complex patterns, effectively optimizing molten pool stirring to reduce porosity and spatter. Utilizing premium F-theta lenses ensures uniform energy distribution across the entire scanning field with stable focal positioning. The modular interface design is compatible with mainstream industrial robot communication protocols, enabling plug-and-play integration. Optimized thermal management structures and multi-layer anti-reflective coated optical components guarantee superior optical performance and extended service life under prolonged high-load conditions.
Technical Specifications
| Model |
HW-Y-8 |
HW-Y-25 |
HW-Y-80 |
HW-Y-160 |
HW-Y-300 |
HW-Y-500 |
| Input Electric |
AC220 50/60 Hz |
AC220 50/60 Hz |
AC380 50/60 Hz |
AC380 50/60 Hz |
AC380 50/60 Hz |
AC380 50/60 Hz |
| Wavelength |
1064nm |
1064nm |
1064nm |
1064nm |
1064nm |
1064nm |
| Output Power |
8 W |
25 W |
80 W |
160 W |
300 W |
500 W |
| Pulse Energy |
5 J |
25 J |
50 J |
50 J |
70/100 J |
70/100 J |
| Pulse width |
15 ms |
15 ms |
15 ms |
15 ms |
15 ms |
15 ms |
| Frequency |
30 Hz |
30 Hz |
100 Hz |
100 Hz |
100 Hz |
100 Hz |
| Power Stability |
± 2.5 |
± 2.5 |
± 3.0 |
± 3.0 |
± 3.0 |
± 3.0 |
| Working Mode |
Pulse |
Pulse |
Pulse |
Pulse |
Pulse |
Pulse |
| Cooling mode |
Air |
Air |
Water |
Water |
Water |
Water |
| Weight |
100 Kg |
100 Kg |
170 Kg |
180 Kg |
220 Kg |
240 Kg |
| Equipment |
1 Kw |
1.2 Kw |
3 Kw |
6 Kw |
12 Kw |
16 Kw |
| Dimension |
955*415*870 mm |
1175mm*515mm*980mm |
1360mm*630mm*1120mm |
Maintenance & After-Sales Support
Routine maintenance primarily involves periodically cleaning protective lenses with oil-free compressed air, inspecting cooling system operation, and verifying cable connection tightness. The equipment comes with a one-year warranty. Our professional technical team provides remote integration guidance to assist clients in optimizing process parameters. Packed in an export wooden case, it supports safe global transportation, complete with operation manuals.
